Custom Stainless Steel Multi-Nozzle Sanitary Distribution Manifold for Food/Pharmaceutical Industry
Introduction
This custom stainless steel multi-nozzle sanitary distribution manifold is specifically designed for high-hygiene applications such as food, beverage, and pharmaceutical industries. It features a sanitary polished surface, multiple precision nozzles, and easy-to-clean design, ensuring uniform fluid distribution while meeting strict sanitary standards (3A, FDA), making it ideal for sanitary fluid distribution systems.
Applications
Food and beverage processing fluid distribution
Pharmaceutical and biotech product distribution
Dairy processing and beverage filling systems
Sanitary water treatment and purification distribution
Features
Sanitary polished inner and outer surface (Ra ≤ 0.8μm), no dead corners, easy to clean and sterilize
Multi-nozzle design (customizable number: 4-15), ensuring uniform sanitary fluid distribution
Food-grade 304/316L stainless steel, conforming to FDA and 3A sanitary standards
Quick-disconnect connections (tri-clamp), easy disassembly for cleaning and maintenance
Specifications
Material: 304/316L stainless steel (food-grade, FDA certified)
Number of Nozzles: 4-15 (customizable)
Nozzle Size: 1/4" - 3/4" (customizable)
Connection Type: Tri-clamp (sanitary standard)
Working Pressure: 0-1.0MPa
Working Temperature: -10℃ ~ 120℃
Customization
Customization services include: number and size of nozzles, nozzle type (sanitary spray, straight), manifold length and diameter, surface finish (mirror polish, electropolish), connection type (tri-clamp, threaded), and material upgrade (316L for higher corrosion resistance) according to your sanitary distribution requirements.
Why Choose Us
Specialized in sanitary distribution manifold manufacturing, familiar with FDA and 3A standards
Strict sanitary inspection: 100% cleaning and sterilization before delivery
Precision machining, ensuring no dead corners and easy cleaning
Free sample available, professional team provides sanitary design advice
Looking for custom stainless steel fabrication solutions?
Send us your drawings or specifications for fast technical support and quotation.
Or please use the following table for reference. Our sales representative will contact you within 24 hours. Thank you for your attention to our products
